Heidolph Hei-FLOW Ultimate 600 Peristaltic Pumps
Item#: 036150110The Heidolph Hei-FLOW Ultimate 600 Peristaltic Pumps give you the ability to switch between precise dosing and fast conveying making this pump model the perfect complement to a reactor system. With a flow rate of 2.0 - 4,056 ml / min, when operated with single-channel pump heads, flows from feed-batch and chemostat modes of operation can be conveyed precisely. Rapid filling and emptying of the reactor system is also possible. In addition to the selectable process parameters - speed, tubing diameter, flow quantity display, dosing volume, interval dosing and break times - the pump conveying characteristics are stored in the program. Thanks to the analogue and digital (RS 232) interfaces, processes can be automated. All media is conveyed with a control accuracy of ±2% at a speed of 24 — 600 rpm. An optional foot switch can be connected for dosing by foot pressure.
$4,484.48 $4,260.26
- Permissible ambient conditions: 5 - 31 °C at 80% rel. humidity 32 - 40 °C, decreasing linearly up to max. 50% rel. humidity
- Weight: 7.3 kg
- Protection class DIN EN 60529: IP 55
- Supply Power: 100 W
- Dimensions (w/d/h): 166 x 256 x 225 mm
- Flow rates single-channel pumps: 2.0 – 4,056 ml/min
- Flow rate accuracy (water without counter pressure): ±2 %
- Speed range: 24 - 600 rpm
- Speed setting: digital
- Electronic speed control: digital
- Control accuracy motor: ±0.5 %
- Select direction of rotation: CW / CCW
- Motor power: 100 W
- Analog interface: for speed 0 - 10 V / 4-20 mA direction of rotation start/stop
- Digital Interface: RS 232
- Flow rate indicator: digital
- Volume dosing: 0.001 – 9,999 ml
- Interval dosing: 0.001 – 9,999 ml in breaks 0.1 sec -750 h
- Smooth start: yes
- Electronic brake: yes
- Foot-pedal connection: yes
- Continuous operation (24/7): yes
- Safety feature: electronic current limiter and overheat protection
- The ability to switch between precise dosing and fast conveying make this pump model the perfect complement to a reactor system. With a flow rate of 2.0 - 4,056 ml / min, when operated with single-channel pump heads, flows from feed-batch and chemostat modes of operation can be conveyed precisely. Rapid filling and emptying of the reactor system is also possible.
- In addition to the selectable process parameters - speed, tubing diameter, flow quantity display, dosing volume, interval dosing and break times - the pump conveying characteristics are stored in the program. Thanks to the analogue and digital (RS 232) interfaces, processes can be automated.
- All media is conveyed with a control accuracy of ±2% at a speed of 24 — 600 rpm. An optional foot switch can be connected for dosing by foot pressure.
Heidolph Hei-FLOW Ultimate 600 Peristaltic Pumps Spec Sheet
DownloadHeidolph Hei-FLOW Series Peristaltic Pumps
