Heidolph Hei-FLOW Core 120 Peristaltic Pumps
Item#: 036150010The Heidolph Hei-FLOW Core 120 Peristaltic Pump is ideal for the simple conveying of all media. The pump drive of this model makes it possible to switch between a single channel and multi-channel pump head. By simply flipping the switch, it can also be conveyed in an anti-clockwise direction. Depending on the adapted pump head, a flow rate of 0.83 - 861 ml/min for the single-channel and 0.005 - 364 ml/min for the multi-channel pump head is guaranteed. The Core 120 conveys with a control accuracy of ± 5% at a speed range of 10 - 120 rpm.
$2,418.48 $2,297.56
- Permissible ambient conditions: 5 - 31 °C at 80% rel. humidity 32 - 40 °C, decreasing linearly up to max. 50% rel. humidity
- Weight: 7.6 kg
- Protection class DIN EN 60529: IP 55
- Supply Power: 100 W
- Dimensions (w/d/h): 166 x 256 x 225 mm
- Flow rates single-channel pumps: 0.83 – 861 ml/min
- Flow rates multi-channel pumps: 0.005 – 364 ml/min
- Flow rate accuracy (water without counter pressure): ±5 %
- Speed range: 10 - 120 rpm
- Speed setting: scale
- Electronic speed control: digital
- Control accuracy motor: ±2 %
- Select direction of rotation: CW / CCW
- Motor power: 100 W
- Continuous operation (24/7): yes
- Safety feature: overheat protection
- This peristaltic pump is ideal for the simple conveying of all media. The pump drive of this model makes it possible to switch between a single channel and multi-channel pump head. By simply flipping the switch, it can also be conveyed in an anti-clockwise direction.
- Depending on the adapted pump head, a flow rate of 0.83 - 861 ml/min for the single-channel and 0.005 - 364 ml/min for the multi-channel pump head is guaranteed. The Core 120 conveys with a control accuracy of ± 5% at a speed range of 10 - 120 rpm.
Multi-Channel Operation
- Increase your throughput by running up to 12 individual cassettes on one single pump drive and pump head system
- Separate metering into multiple vessels with different feed rates in a single operation by using different tubing dimensions to adjust flow rate
- Save time: tubing change is done in just seconds
- In addition to standard pump heads which feature a 4-roller system you can choose 8-roller pump heads for low pulsation
- Change your cassettes easily, even during operation – there are no restrictions
- Cassette adjustments and changes are simple, just click in place
- No additional purchase of a pump drive needed: upgrade your single-channel pump drive with just one adaptor for multi-channel use and pick the head/cassette configuration that matches your application needs
Heidolph Hei-FLOW Core 120 Peristaltic Pumps Spec Sheet
DownloadHeidolph Hei-FLOW Series Peristaltic Pumps
