Heidolph Hei-FLOW Expert 600 Peristaltic Pumps
Item#: 036150070The Heidolph Hei-FLOW Expert 600 Peristaltic Pump has a flow rate of 2.0 — 4,056 ml/min and is designed for operation with single channel pump heads. The analog interface makes it possible that all functions can be controlled externally. A control accuracy of ±3.5% and a conveyor speed of 24 to 600 rpm provide optimum process conditions. In addition, sensitive media can be protected from influence by using the optional foot switch. Like all Heidolph peristaltic pumps, the conveying direction of this model can be changed by a simple push of a button. Furthermore, the accelerated filling and emptying of the tubing is simplified, since here only the button for the maximum speed has to be pressed.
$3,429.61 $3,258.13
- Permissible ambient conditions: 5 - 31 °C at 80% rel. humidity 32 - 40 °C, decreasing linearly up to max. 50% rel. humidity
- Weight: 7.3 kg
- Protection class DIN EN 60529: IP 55
- Supply Power: 100 W
- Dimensions (w/d/h): 166 x 256 x 225 mm
- Flow rates single-channel pumps: 2.0 – 4,056 ml/min
- Flow rate accuracy (water without counter pressure): ±3.5 %
- Speed range: 24 - 600 rpm
- Speed setting: scale
- Electronic speed control: digital
- Control accuracy motor: ±0.5 %
- Select direction of rotation: CW / CCW
- Motor power: 100 W
- Analog interface: for speed 0 - 10 V / 4 - 20 mA direction of rotation start/stop
- Foot-pedal connection: yes
- Continuous operation (24/7): yes
- Safety feature: electronic current limiter and overheat protection
- This model has a flow rate of 2.0 — 4,056 ml/min and is designed for operation with single-channel pump heads. The analog interface makes it possible that all functions can be controlled externally. A control accuracy of ±3.5% and a conveyor speed of 24 to 600 rpm provide optimum process conditions. In addition, sensitive media can be protected from influence by using the optional foot switch.
- Like all Heidolph peristaltic pumps, the conveying direction of this model can be changed by a simple push of a button. Furthermore, the accelerated filling and emptying of the tubing is simplified, since here only the button for the maximum speed has to be pressed.
Heidolph Hei-FLOW Expert 600 Peristaltic Pumps Spec Sheet
DownloadHeidolph Hei-FLOW Series Peristaltic Pumps
