Accuris SmartDrop™ XF Nano Spectrophotometer + Fluorometer, 115V
Item#: NS1020This top of the line spectrophotometer can perform not only UV-Vis readings in the range of 200-800nm but also fluorescence readings. Like the SmartDrop X, the SmartDrop XF features predefined programs for nucleic acids, proteins, and various colorimetric assays. The patented, motorized system gently stretches the sample column and allows for three different path lengths, providing accurate readings of samples from 0.5 to 2.0µl without dilution.
$13,639.50 $12,275.55
- Product Specifications
- Product Features
- Literature & Manuals
- Product Videos
- Product Accessories
- Request a Proposal
- Display: 7-inch touch screen
- Minimum sample size: 0.5μl - 2.0μl
- Path length: 0.05mm, 0.2mm, 1.0mm
- Light source: Xenon Flash Lamp
- Detector: 2048 Element Linear Silicon CCD Array
- Wavelength: 200 – 800nm (1nm steps)
- Absorbance range: 0.04 – 300 A (10mm equivalent)
- Absorbance precision: 003 A
- Lower limit of detection: dsDNA: 2ng/µl; BSA: 0.1mg/ml
- Upper limit of detection: dsDNA: 15,000ng/µl; BSA: 360mg/ml
- Detection time: < 6 seconds
- Communications ports: USB for data export
- Voltage Input: DC 24V, 2A
- Power: 25W
- Dimensions (WxDxH): 20.8 x 8.0 x 18.6 cm / 8.2 x 11.0 x 7.3 in.
- Weight: 3.6 kg / 7.9 lbs
Cuvette 0D600 detection
- Absorbance range: 0.0 - 4.0 A
- Absorbance stability: [0,3) ≤ 0.5%, [3,4) ≤ 2%
- Absorbance repeatability: [0,3) ≤ 0.5%, [3,4) ≤ 2%
- Absorbance precision: [0,2) ≤ 0.005 A, [2,3) ≤ 1%, [3,4) ≤ 2%
Fluorescence detection
- Excitation/Emission: 460 ± 20nm / 525-570nm
- Sensitivity: dsDNA: 0.5pg/µl
- Linearity: R² ≥ 0.995
- Repeatability: ≤ 1.5%
- Stability: ≤ 1.5%
- Full-spectrum absorbance scanning and calculations of 260/280 and 260/230 ratios
- Long-life Xenon lamp with precision monochromator
- Auto-ranging path lengths of 0.05mm, 0.2mm and 1.0mm
- Detect up to 15,000ng/µl of dsDNA without dilution
- Integrated fluorometer for sensitive quantitation of low concentration nucleic acids
Accuris Instruments SmartDrop Spectrophotometers Literature
DownloadAccuris SmartDrop™ XF Nano Spectrophotometer Overview
-
Broad Range DNA Quantification Kit for Accuris SmartDrop Spectrophotometers | 100 assays
Item #: NS1020-BR-100$133.93$120.54 -
Extra Paper Roll for Accuris SmartDrop Spectrophotometers Internal Printer | Qty 3
Item #: NS1000-PA$42.84$38.56 -
High Sensitivity DNA Quantification Kit for Accuris SmartDrop Spectrophotometers | 100 assays
Item #: NS1020-HS-100$133.93$120.54 -
0.5mL Fluorescence Detection Tubes for Accuris SmartDrop Spectrophotometers | Pack of 250
Item #: NS1020-T$58.96$53.06 -
Additional Standard-Size Cuvettes for Accuris SmartDrop Spectrophotometers | Qty 2
Item #: NS1000-C$53.55$48.20
